Product Characteristics
Model No.
Warranty Product Warranty 12 Years Power Warranty 12 Years of 94.60% Output Power, 25 Years of 89.4% Output Power Electrical Data at STC Maximum Power (Pmax)
SS345M10 SS350M10 SS355M10 SS360M10 SS365M10
345 Wp 350 Wp 355 Wp 360 Wp b 365 Wp
Voltage at Maximum Power (Vmpp)
32.97 V 33.18 V 33.37 V 33.58 V 33.77 V
Current at Maximum Power (Impp)
10.47 A 10.55 A 10.64 A 10.73 A 10.81 A
Open Circuit Voltage (Voc)
38.22 V 38.45 V 38.68 V 38.91 V 39.15 V
Short Circuit Current (Isc)
11.31 A 11.4 A 11.49 A 11.58 A 11.67 A
Panel Efficiency
17.7 % 17.9 % 18.2 % 18.4 % 18.7 %
Power Tolerance (Positive)
+ 1.5 % + 1.5 % + 1.5 % + 1.5 % + 1.5 %
Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C Electrical Data at NOCT Temperature 45±2 °C Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C Thermal Ratings Operating Temperature Range -40~+85 °C Temperature Coefficient of Pmax -0.290 %/°C Temperature Coefficient of Voc -0.250 %/°C Temperature Coefficient of Isc +0.045 %/°C Maximum Ratings Maximum System Voltage 1500 V Series Fuse Rating 25 A Material Data Panel Dimension (H/W/D) 1722x1134x30 mm Weight 20.5 kg Cell Type TOPCon Cell Number 108 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Alloy Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 1200 mm
